产品型号:pb05
charging mode:piq
interface:micro usb input, usba output
input:5v/2a
output:5v/2.4a
battery type:lithium ion polymer battery
power:output:12w
dimension:125*59.8*11.9mm
capacity:5000mah
weight:145g
housing material:aluminum alloy
applicable environment:0-50℃
certification scope:ccc,bsmi
产品详情

1.automatic identify input and select different charge current;

2.ultra low standby consumption , high efficiency charge and discharge;

3.using high performance lithium ion battery, it is durable, after 3000 times full charge and discharge cycles, the battery  still has more than 80% of original battery capacity ;

4.battery capacity display:  gently shake the power bank once, the led will indicate battery capacity;

5.battery overcharge,over-discharge protection, over-current protection, over-temperature protection and other protection functions are available, safe and reliable.


protect function:

1.input overvoltage and undervoltage protection;

2.output overvoltage protection;

3.output short-circuit protection;

4.battery overcharge,overdischarge,overcurrent and short-circuit protection;

5.overtemperature protection;

6.build-in ptc and battery protection ic for battery protection;

7.output overload protection;

8.aluminum alloy housing provides comprehensive protection.
